| DESCRIPTION | PARKING | |
|---|---|---|
| TYPE & OPERATION METHOD OF PARKING DEVICE | OUTDOOR VERTICAL ROTATION TYPE | |
| VEHICLES SPECIFICATIONS | LENGTH | 5200 MM |
| WIDTH | 2500 | |
| HIEGHT | 2000 | |
| WEIGHT | 2000KG | |
| SPCIFICATION OFDRIVE PART | DRIVE MOTOR | 5.5 KW |
| DRIVE DECELERATOR | HEICAL WORM=1/140 | |
| BRAKE | AC”B”TYPE DISK BRAKE | |
| ROTATING SPEED | 3.5M/MIN | |
| ROATING TYPE | VERTICAL ROTATION BY CHAIN AND SPROCKET | |
| SPECIFICATION OF PALLET | SIZE | 2300WX500OL |
| SELF WEIGHT | 800KG | |
| STRUCTURE | STEEL PLATE BEDING | |
| SPECIFICATIONS OF ELECTRIC CONTROL PART | MOTOR CONTROLLER | LINE START DRIVE |
| CONTROL TYPE | MICO TYPE (BASIC) | |
| CONTROL METHOD | PUSH BUTTON BASIC | |
| POWER SOURCE | ||
| NO OF CARS | HEIGHT OF EQUIPMENT | DIMENSION |
|---|---|---|
| 06 | 7600MM | 6000Wx5500L |
| 8 | 9450 | |
| 10 | 13150 | |
| 12 | 11300 |
